LWIR Camera

VIPER is a revolutionary intelligent, high-resolution LWIR thermal camera, designed for vehicle safety and perception systems to enhance ADAS and enable all levels of automation. It is the only automotive grade shutterless thermal camera available that can see and detect what other sensors cannot, day or night, without being compromised by complete darkness, blinding lights or harsh weather.

SPECIFICATION

Spectral Responsivity
LWIR 7.5 ~ 13.5 𝜇𝚖
Resolution
640 * 480 / 30 fps
High Sensitivity
0.05℃

(NETD <50mK)

Non-Uniformity
Correction
Shutterless
Low Latency
< 2ms
Small Form Factor
∅26mm x 44mm
< 55g
Detection Range

200m (FOV 18˚)
120m (FOV 30˚)

Certification

ISO 26262 ASIL B
AEC Q100 Grade 2

  • Embedded Shutterless FIR Algorithms
  • IO connectivity : GMSL / Ethernet / FPD-Link Ⅲ
  • Waterproof : IP68 (IP69K Expected MP)
  • ISP ASIC : No FPGA
